The RotaChock® BasicLine has the following design features:

1. Spherical top ring for angular difference up to 4° between the machine foot and the foundation.

2. Tool groove and holes to aid installation with a wide range of tools.

3. Buttress thread design for maximum strength and stiffness.

4. Standard ACE finish: Anti-Corrosion Enhanced for cost-effective corrosion protection.

5. The footprint is large and reduces surface pressure.

6. Type Approved by all major classification societies.

The RotaChock® SlimLine has the following design features:

1. Spherical top ring for angular difference up to 2° between the machine foot and the foundation.

2. Tool groove and holes to aid installation with a wide range of tools.

3. Buttress thread design for maximum strength and stiffness.

4. Standard ACE finish: Anti-Corrosion Enhanced for cost-effective corrosion protection.

5. The footprint is large and reduces surface pressure.

6. Type Approved by all major classification societies.

The RotaChock® Mounting PLate has the following design features:

1. Spherical top ring for angular difference up to 2° between the machine foot and the foundation.

2. Tool groove and holes to aid installation with a wide range of tools.

3. Buttress thread design for maximum strength and stiffness.

4. Standard ACE finish: Anti-Corrosion Enhanced for cost-effective corrosion protection.

5. The footprint is large and reduces surface pressure.

6. Type Approved by all major classification societies.

The Spherical Spacers accomplish two functions: creating hardware planes and bolt elongation. This solution comprises two parts with a smooth concave and convex curvature, resulting in an angular offset angle of 4°, which creates the hardware plane. The standard heights elongate the bolt and create extra clamping length.

These small-sized Hexagon RotaChock® are ideal for small equipment like pump sets where accurate alignment is still crucial. This solution has the same principle as all RotaChock®: an adjustable threaded center for parallel differences and a spherical top to overcome angular differences. Thanks to the hexagonal design, adjustment is performed with a simple wrench/spanner.

Many times, the adjustment range of RotaChock® is sufficient to accommodate the differences. But if 5 to 25 mm in additional height is needed, then a taller top ring is more economical than other solutions. Stocking sets of Taller Top Rings can save you time during assembly when you find yourself slightly out of your designed gap height.
The standard Taller Top Rings are manufactured from S355 (DIN1.0570) and are Anti-Corrosion Enhanced for cost-effective corrosion protection.
